Center Drive System
Solid Virgin Grade Poly Floor & Sides
Channel Floor Supports Spaced at 9½” for Superior Strength
Easily Removable Beater Assembly

•  All horizontal beater hydraulic push models use solid virgin grade poly with UV inhibitor for the floor and sides, allowing less friction.
•  The hydraulic endgate has two cylinders with ?" hose and pipe for faster operation in cold weather.
•  Heavy-duty rectangular tubing is used for the pole to ensure strength and long life.
•  Structural channel floor supports are spaced 9 ½" apart are used for maximum floor strength.
•  Driveline protection is provided by a constant velocity PTO and straight shaft under the spreader connect to the rear mount angle gearbox, over to the beater drive sprocket, and then to the beater assembly.
•  The hydraulic push-off system on all models features two hydraulic cylinders that sequence to reduce push-off forces for fast unloading of material.
•  Beater blades are replaceable.
•  Beater assembly is removable for stockpiling manure.
•  Removal of the beater assembly is done by simply removing the mounting bolts and removing the drive chain to the beater assembly.
•  Choice of bullnose or clevis hitch
•  Poly bump rails
•  LED highway lighting
